Technical Specifications Detector Type: Amorphous Silicon (a-Si) with CsI Scintillator Active Area: 17×1717×17 inches (460×460460×460 mm) Pixel Matrix: 3072×30723072×3072 Pixel Pitch: 139 μm Spatial Resolution: 3.6 lp/mm AD Conversion: 16-bit Trigger Modes: AED (Optional), Software, Prep Dimensions: 460×460×15460×460×15 mm (18.1×18.1×0.618.1×18.1×0.6 in) Weight: 4 kg (8.8 lbs)

Model: JYF-10D (Stand Type) Power Supply: AC220V± 10%, 50Hz, 1kVA Tube Voltage: 60 kVp Tube Current: 10 mA Focus Size: 1.5 mm Total Filtration: 2.5 mmAl Exposure Time Range: 0.2 – 4 seconds Leakage Radiation: < 0.002 mGy/h (at 1 meter)

The HMC-160D is a high-performance mobile C-Arm system built for advanced surgical and interventional procedures. With its powerful 16kW generator and large-format flat panel detector, it delivers exceptional image clarity for both routine and complex cases, including optional DSA functionality for peripheral angiography.
